41U 4 Post Knockdown Open Frame Rack
41U 4 Post Knockdown Open Frame Rack
Made in the USA
Limited Lifetime Warranty
Certifications
19" EIA compliant
Description
The 41U Knockdown 4-Post Open Frame Rack by Kendall Howard is a powerhouse in adjustable open-frame knockdown racks. Crafted with the utmost precision, our unique and heavy-duty square tube steel design assembles effortlessly with just a few bolts, ensuring affordability, versatility, and seamless shipping. It arrives via ground shipping in a compact package ready for assembly. Trust the reliability and convenience of the 41U Knockdown 4-Post Open Frame Rack for all your racking needs.
- Fully adjustable rails from 3" to 36"
- Assembles in less than 45 minutes
- 2,000 lb. weight capacity
- 19" EIA compliant
- Made in the USA
- Limited Lifetime Warranty
Features
Mount More Rails
Unlike most 4-post racks that limit mounting options to only two sets of vertical rails, our innovative design offers the flexibility to add a third set of rails. This unique feature allows you to conveniently mount equipment with varying depths in the same rack, maximizing efficiency and convenience.
Ships in Knockdown Position
Our rack’s clever knockdown design enables us to ship the product as a compact package, minimizing shipping expenses while ensuring delivery to virtually any location worldwide.
Height Adjustable Levelers
Levelers are provided to ensure convenient and effortless installation, along with seamless adjustability for precise height customization.
Front and Rear Rails
Our 41U 4 Post Knockdown Rack includes two sets of adjustable 41U cage nut style rails.
Specifications
| Part Number | 1943-3-100-41 |
| Width | 23.4" |
| Depth | 36.2" |
| Height | 74.9" |
| Weight | 98lbs |
| Shipping Dimensions | 75"x 8"x 5" |
| Material(s) | Cold Rolled Steel |
| Color/Finish | Black |
| UPC | 879447006384 |
| Warranty | Limited Lifetime Warranty |
| Shipping Method | FedEx Ground |
What's in the Box
| Item | Quantity |
|---|---|
| Upright Tube | 4 |
| Corner Gusset | 8 |
| Cross Tube | 4 |
| Cage Nut Style Rack Rail | 4 |
| Side Tube Weldment | 4 |
| 3/8-16 X .750 Button Head Screw | 8 |
| 5/16-18 X .750 Button Head Screw | 32 |
| 3/8-16 Channel Nut | 8 |
| 3/8-16 X 1.00 Button Head Screw | 16 |
| Levelers | 4 |
Resources
| Title | Type | Date | Version | File Size | |
|---|---|---|---|---|---|
Title 41U Knockdown 4 Post Open Frame Rack 1943-3-100-41 STEP File |
Type 3D CAD |
Date 01/24 |
Version 1 |
File Size 1,012.41 KB |
Download |
Title 41U Knockdown 4 Post Open Frame Rack 1943-3-100-41 Instructions |
Type Instructions |
Date 01/24 |
Version 1 |
File Size 856.61 KB |
Download |
Title 41U Knockdown 4 Post Open Frame Rack 1943-3-100-41 Data Sheet |
Type Data Sheet |
Date 01/24 |
Version 1 |
File Size 123.24 KB |
Download |
Title 41U Knockdown 4 Post Open Frame Rack 1943-3-100-41 Cut Sheet |
Type Cut Sheet |
Date 01/24 |
Version 1 |
File Size 307.36 KB |
Download |
